Outline Electric Radiators

Electric Outline radiators combine beauty with technical excellence. Designed and manufactured in the UK they celebrate the best of British. Made to order, these handsome items come in a whole host of shapes and sizes and can be finished in brushed stainless steel and a whole host of colours, pioneering electric radiator design.

  • Made in the UK
  • Huge range of sizes and finishes
  • Upgrade with integral wireless receivers to ensure efficiency



Reset Options
£924.52
In stock
SKU
OUTLINE/EL
Calculate My Heat Requirements

Lead Time:Approximately 6 to 8 weeks

What our Customers Say About Us...

""

From

Know what heat output you require? Enter it into the below field and we'll let you know if a radaitor is right for your room.

Not sure what output you need to fill your room with heat? Complete the form below to calculate your required heat output.

My house was built after 2002 or is well insulated (part L compliant)

My room is north facing.

My room has French doors / large window.

My room has single glazed windows.

My room is exposed & colder.

Please select your Delta T Value

Using the dropdown below, please set your Delta T Value for use throughout the site...

Set Delta T Value

IMPORTANT INFORMATION

  • Lead time: All Outline radiators are by special order in approximately 6 to 8 weeks. Special order means that an order cannot be cancelled once manufacturing has commenced.
  • Regards temperature control - the WIFI option means control away from the home and via an app, it includes a wall thermostat which sense the temperature in the home and that can have multiple radiators linked to it. The classic thermostat is a wall mounted stat that has a dial for operation on the device, 7 day programming can be set for each day, holiday mode and boost mode etc, this a manual control and the desired temperature set is detected by this thermostat.
  • If you are buying multiple Outline electric radiators please call or email as you need not buy the controls on each product, so we can advise further here and reduce costs
  • Delivery to Scotland and highlands just on this products draws a higher cost, sorry not us, the manufacturer
  • Finishes: Choose from a range of RAL colours, "Blackboard", brushed stainless steel or special finishes for the prices as listed. Maggie, Fop and Compost are special textured paint finishes. Swatches available on request. Colour matching service is also available - please contact our sales team for a quote. Alternative finishes on this design of radiator are also available, please see Electric Supermirror, Cliff, Gong!, Blackboard and Woody ranges.
  • Design: Bespoke sizes are also available - please ask for a quote. The Outline is a modular aluminium high output radiator with a front fascia panel. This means that the radiator has a low surface temperature and acts as a convector heater and emits heat from the space at the top of the radiator between the wall and the rear of the radiator as opposed to the front panel. There is a 25mm gap from wall to rear of radiator on all Outline models.
  • Towel rails: Towel hanging rails can be added to Outline radiators for a surcharge - please contact our sales team for a quote.
  • Controls: Electric heating element is non-adjustable (on/off) without a timer as standard. However, this electric radiator can be upgraded to add extra functions and controls, via in-house controllers or via an app on your device(s); the aim being to minimize energy wastage and maximise efficiency - contact our sales team for more information.
  • Installation: The power cable is located at the bottom right hand corner of the radiator but can be placed behind the radiator facade, so it is out of view (as pictured).
  • Material: Made of aluminium with a stainless steel or mild steel front fascia panel.
  • Delivery: We offer delivery to most addresses on the UK mainland (excluding some remote areas).
  • Fixings: Radiators are supplied with the necessary fixings i.e. wall bracket, plugs, bushes and vents. Screws are not supplied.
  • Depth: 50mm or 95mm
  • Projection from the wall: 50mm deep models = 75mm / 95mm deep models = 120mm (measurements exclude chalk holder)
  • Manufacturer's guarantee: 2 year manufacturer's guarantee against manufacturing defects.
  • Terms and Conditions: All sales are subject to our standard Ts and Cs; a copy can be downloaded from our website.
  • VAT: The prices shown are inclusive of VAT.
More Information
Featured Product No
Price shown is for white paint finishes. For more information see ADDITIONAL INFORMATION page.
Download Printer Friendly Price List Printer Friendly
HeightWidthFinish Element Wattage Price incl VAT
290mm1100mmStandard Colour 394 £924.52
750mm460mmStandard Colour 580 £969.30
1400mm240mmStandard Colour 580 £975.46
290mm1100mmStandard Colour 578 £989.38
750mm460mmStandard Colour 820 £1,032.66
1400mm240mmStandard Colour 820 £1,043.45
290mm1600mmStandard Colour 592 £1,071.30
700mm700mmStandard Colour 870 £1,127.00
1900mm240mmStandard Colour 870 £1,134.66
290mm1600mmStandard Colour 868 £1,136.29
470mm1100mmStandard Colour 789 £1,170.29
290mm2100mmStandard Colour 789 £1,215.08
1900mm240mmStandard Colour 1230 £1,241.42
470mm1100mmStandard Colour 1157 £1,269.16
700mm700mmStandard Colour 1230 £1,276.93
1400mm460mmStandard Colour 1160 £1,310.93
290mm2100mmStandard Colour 1157 £1,338.78
1400mm460mmStandard Colour 1640 £1,429.99
650mm1100mmStandard Colour 1183 £1,437.65
470mm1600mmStandard Colour 1183 £1,456.21
650mm1100mmStandard Colour 1735 £1,575.28
470mm1600mmStandard Colour 1735 £1,589.20
470mm2100mmStandard Colour 1578 £1,719.30
1900mm460mmStandard Colour 1740 £1,793.45
650mm1600mmStandard Colour 1775 £1,819.55
470mm2100mmStandard Colour 2313 £1,840.00
1900mm460mmStandard Colour 2460 £1,916.15
1050mm1050mmStandard Colour 1578 £1,927.82
650mm1600mmStandard Colour 2603 £1,936.98
1050mm1050mmStandard Colour 2890 £2,031.32
650mm2100mmStandard Colour 2367 £2,201.45
